Exhaust Blower- Pelpro/ Glow Boy/ Cheap Charlie (Combustion / Draft) - KS-5020-1040 - Replaces ACCBFNAS- 1 male (white) & 1 female clip
This Pelpro combustion fan / exhaust (draft) blower fits Pelpro, Glow Boy & Cheap Charlie pellet stoves. Part # KS-5020-1040. Replaces part # ACCBFNAS. Blower comes with quick change housing for easy motor and impeller cleaning and replacement. Also includes housing gasket, exhaust venting flange gasket and wires to plug into stove's wire harness.
The exhaust fan and snap disc must be removed from the old blower and attached to this new blower.
The exhaust flange must be screwed on and sealed with high temp silicone.The snap disc must be screwed on with self tapping screws.
Fits the following models:
Pelpro & Glow Boy
- Home Heater
- Home Heater 120 (HHPP2BD)
- Home Heater 300 (HHPP32BD)
- Shop Heater
- Shop Heater 120
- Shop Heater 300
- FBG Step Top
- FGB Bay View
- IGB Bay View
- Classic Insert
- Standard Freestanding PP60
- Standard Freestanding FPP2BD
- Step Top FPPST4BD
- Bay Window Freestanding FPPBW2GD
- Bay Window Insert IPPBW2GD
- Shepard Bay
- CC Edison Jr.(HCJ)
- CC Edison Sr. (HCS)
- CC Franklin300 (HCF 300)
- CC Franklin120 (HCF 120)
- Also fits many Vulacan Wood Pellet Stoves
This also fits the following models:
Just use the original vent flange and screw and silicone it on.
Exhaust vent flange is also available to order here:
We also have the universal 3" diameter exhaust flange here
The exhaust blower blows ash up the venting and draws outside air into the firebox and across the heat exchange. It is also known as a centrifugal blower.
The wire connections included are one male spade clip and one female spade clip that will plug into the existing stove's wire harness.
